Linz Alternator Welding Generator 130A 200A 220A 250A

The diesel generator trailer with  brake features an "A" style frame with a retractable and adjustable supporting wheel. It is equipped with 4 drawable bars with manual jacks for stabilization and 14" rims with regular tires. The tow adapter supports a 2" ball coupler or a 3" pintle ring. Trailer a tail reflector, and the maximum towing speed is 60 km/h.

The 1000kVA generator powered by Perkins 4008-30TAG2 engine which renowned for its reliability, durability, and efficiency. It delivers a robust power output and is engineered to withstand the most demanding applications, making it ideal for industrial, commercial, and residential use.

Output range: from 15kVA up to 113kVA(50Hz), 20kVA up to 125kVA(60Hz) Engine models: JE493DB-03, JE493DB-01, JE493ZDB-03, JE493ZLDB-01.  Alternator: Stamford, Marathon, Leroy Somer, Mecc Alte, and Chinese brands with brushless and "H" Class Insulation. 8hrs operation base tank Key start (power switch) / autostart Open type / sound-proof / weather-proof canopy / mobile type are optional 50Hz / 60Hz, 0.8 PF 1-phase/ 3-phase

Model Standby Power  Prime Power Engine Model Dimension Open Type Weight Datasheet kVA kW kVA kW LXWXH(MM) KG A-KF22 22  18  20  16  4YT23-20D 1550x800x1350 750 Download A-KF28-1 28  22  25  20  4YT23-30D 1550x800x1350 780 Download A-KF28-2 28  22  25  20  K4100DS 1550x800x1350 780 Download A-KF28-3 28  22  25  20  N4100DS-30 1550x800x1350 780 Download A-KF33-1 33  26  30  24  N4100DS-30 1550x800x1350 800 Download A-KF33-2 33  26  30  24  K4100DS 1550x800x1350 800 Download A-KF41-1 41  33  38  30  K4100ZDS 1550x800x1350 850 Download A-KF41-2 41  33  38  30  N4105DS-38 1550x800x1350 850 Download A-KF47 47  37  43  34  K4100ZDS 1550x800x1350 880 Download A-KF55-1 55  44  50  40  N4105DS-42 1550x800x1350 950 Download A-KF55-2 55  44  50  40  N4105ZDS 1550x800x1350 950 Download A-KF55-3 55  44  50  40  R4105DS 1550x800x1350 950 Download A-KF55-4 55  44  50  40  R4105ZDS 1550x800x1350 950 Download A-KF69-1 69  55  63  50  N4105ZDS 1750x900x1350 980 Download A-KF69-2 69  55  63  50  N4105ZLD 1750x900x1350 980 Download A-KF69-3 69  55  63  50  R4105ZDS 1750x900x1350 980 Download A-KF69-4 69  55  63  50  R4105ZLDS 1750x900x1350 980 Download A-KF83-1 83  66  75  60  R4105ZLDS 1750x900x1350 1050 Download A-KF83-2 83  66  75  60  R4105BZLDS 1750x900x1350 1050 Download A-KF83-3 83  66  75  60  N4105ZLD 1750x900x1350 1050 Download A-KF88 88  70  80  64  R6105ZDS 2150x1080x1500 1050 Download A-KF103-1 103  83  94  75  R6105ZDS 2150x1080x1500 1200 Download A-KF103-2 103  83  94  75  4RT55-88D 1750x900x1350 1200 Download A-KF110 110  88  100  80  4RT55-110D 1750x900x1350 1250 Download A-KF125 125  100  113  90  R6105ZLDS 2150x1080x1500 1300 Download A-KF138-1 138  110  125  100  4RT55-110D 1750x900x1350 1380 Download A-KF138-2 138  110  125  100  R6105AZLDS 2500x980x1650 1380 Download A-KF165-1 165  132  150  120  R6105BZLDS 2500x980x1650 1400 Download A-KF165-2 165  132  150  120  6RT80-132D 2500x980x1650 1400 Download A-KF206-1 206  165  188  150  6RT80-176D 2500x980x1650 1480 Download A-KF206-2 206  165  188  150  R6110ZLDS 2500x980x1650 1480 Download A-KF220 220  176  200  160  6126-68DE 2530x980x1650 1500 Download A-KF248 248  198  225  180  6126-42DE 2530x980x1650 1560 Download A-KF275 275  220  250  200  6126A-260DE 2530x980x1650 1580 Download A-KF303 303  242  275  220  6127A-275DE 2930x1080x1650 1650 Download A-KF385-1 358  286  325  260  WT12D-308E 2930x1080x1650 2450 Download A-KF385-2 385  308  350  280  WT12D-330DE 2930x1080x1650 2450 Download A-KF385-3 385  308  350  280  WT13D-330DE 2930x1080x1650 2450 Download A-KF440 440  352  400  320  WT13-360DE 2930x1080x1650 2800 Download A-KF500 500  400  450  360  WT13A-390DE 2930x1080x1650 2800 Download

Assembly by Cummins brand new engine and brand new single bearing alternator with IP23, class H. Options alternator Brands: Stamford, Leroy Somer, Marathon, Mecc Alte, Hosem, etc. Heavy-duty steel as the base plate with 8 hours operation fuel tank.  The extremely low noise level, the canopy is made of 2mm cold-rolled sheet, filled with 3cm thick flame retardant muffler cotton, complete gen-set with heavy-duty industrial type silencer with flexible bellow and elbow. Vibration damper between engine/alternator and base frame 3-pole circuit breaker. Options Controller brands: UK Deepsea, Czech ComAp, CN Smartgen etc. Full range protect function and alarm shutdown feature Comply with ISO8528 national standard and ISO9001 quality standard.

Engine Model: CCEC KTA19 series Engine Type: 6-cylinder inline, four-stroke Displacement: 18.9 liters Bore and Stroke: 159 mm (6.25 in) x 159 mm (6.25 in) Fuel System: PT fuel system Cooling System: Water-cooled Turbocharger: Yes Aftercooler: Yes Governing System: Electronic or mechanical governor Starting System: Electric start Alternator Type: Brushless, self-excited Control Panel: Deepsea/ Smartgen Voltage Regulation: Automatic voltage regulation (AVR) Enclosure: Soundproof or weatherproof enclosure (optional) Fuel Tank: Integrated fuel tank (optional)

Combining a heavy-duty diesel engine, it allows for 24 hours of continuous operation.   It features a waterproof design with high-quality paint for superior anti-corrosion performance.   Additionally, it can be equipped with a remote control system, allowing for easy monitoring of the generator through the internet or via a SIM card.   Comes with a two-wheeled trailer and mechanical brakes, with a maximum speed of 50 km/h.
